Assembly
4.3 Mounting with the Weinmann LIFE-BASE adapter (option)
By clicking it directly into place:
–
By attaching it via the respective fixation holes:
–
–
–
–
–
4.3.1 Weinmann LIFE-BASE 3NG
1. Place the adapter with the horizontal bar facing down in the Weinmann LIFE BASE 3NG
2. Insert the adapter with the U-shaped notch up into the holder and let it click into place.
3. Tightly screw the carrying system holder to the adapter as described in chapter
4. Make sure that the adapter is properly secured.
4.3.2 Weinmann LIFE-BASE 4NG, LIFE-BASE II, LIFE-BASE Mini II, LIFE-BASE III, Dräger
all-round wall holder
Risk of patient injury and damage to the device
If the adapter is not mounted correctly, it may fall and injure the patient.
► When mounting the adapter, always use suitable spacing bolts, as the adapter will
1. Remove the existing holder.
2. From the set of spacing bolts included, select the most suitable spacing bolts and screw
3. Search the adapter for the correct hole pattern and tightly screw the adapter to the
4. Tightly screw the carrying system holder to the adapter with the M6 screws as described
4.4 Mounting with the Dräger all-round wall holder adapter (option)
adapter:
1. Place the lower edge of the adapter into the socket of the all-round wall holder.
2. Click the upper edge of the adapter into the all-round wall holder.
3. Tightly screw the carrying system holder to the adapter as described in chapter
4. Make sure that the adapter is properly secured.
22
The carrying system holder can be attached to the following holders using the adapter:
Weinmann LIFE-BASE 3NG
LIFE-BASE II
LIFE-BASE Mini II
LIFE-BASE III
LIFE-BASE 4NG
Dräger all-round wall holder
holder.
"Mounting on the wall without the angled plate".
WARNING
otherwise not be stable enough.
them tightly into all of the holes.
spacing bolts using the correct screws.
in chapter "Mounting on the wall without the angled plate".
The carrying system holder can be attached to the Dräger all-round wall holder with the
"Mounting on the wall without the angled plate".
