General description

The illustrations are on the
front and back fold-out page.

Extent of the delivery

Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- Storage case
- Instruction manual
The rechargeable battery and
charger are not included in delivery.

Overview

1 Drill chuck aperture
2 Keyless drill chuck
3 Torque adjustment ring
4 Speed selector
5 Bit holder
6 Button for charge status display
7 Battery Indicator
8 Battery
9 Battery release button
10 LED working light
11 Direction of rotation switch
12 On/off switch
13 Storage case
14 Charger
15 Metal belt clip

Functional description

The cordless drill with two-speed gearing
has a 25+1 level torque adjustment, left/
right running, a removable keyless chuck
and an LED working light. Please refer to
the descriptions below for information on
how the operating elements work.

Technical data

Cordless Drill ........... PABS 20-Li G8
Motor voltage U ..........................20 V
Idling speed n
0
1st gear .............................0-430 min
2nd gear .........................0-1500 min
Maximum torque .......................... 45 Nm
Span-chuck Ø ........................ 1.5-13 mm
Weight (with battery, 2 Ah) ............ 1.7 kg
Drilling capacity
for wood .......................... max. 30 mm
for steel ........................... max. 13 mm
Protection category........................... IPX0
Temperature...........................max. 50 °C
Charging process ...................4 - 40 °C
Operation .......................... -20 - 50 °C
Storage .................................0 - 45 °C
Sound pressure level
(L ) ........................72.1 dB, K
pA
Sound power level
(L ) ...................... 83.1 dB; K
WA
Vibration (a )
h
...................... <2.5 m/s
For use with smart batteries
(Smart PAPS 204 A1/Smart PAPS 208 A1)
Operating frequency/
Frequency band .....2400 - 2483.5 MHz
Max. transmission power ....... ≤ 20 dBm
Noise and vibration values have been de-
termined according to the standards and
regulations mentioned in the declaration of
conformity.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to
compare one power tool to another.
The stated vibration emission value may
also be used for a preliminary exposure as-
sessment.
GB
-1
-1
= 5 dB
pA
= 5 dB
WA
K= 1.5 m/s
2; 2
5
