manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
The device is part of the X 20 V TEAM
series and can be operated with bat-
teries of the X 20 V TEAM series. Bat-
teries of the X 20 V TEAM series may
only be charged using chargers of the
X 20 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Charger
• Translation of the original instructions
The rechargeable battery is not in-
cluded in delivery.
Overview
The illustrations for the
device can be found on the
front fold-out page.
1 Battery release
2 Button (Charge level indicator)
3 Charge level indicator
4 Battery
5 Charger
6 Control display
7 Charging slot
Technical data
Dual Battery Charger
................................ PDSLG 20 B1
Rated voltage U ......230–240 V∼, 50 Hz
Rated output P ................................ 220 W
Protection class ..... ⧈ II (double insulation)
Device fuse ..................................... T3.15A
Output 1:
Output voltage ................................ 21.5 V
16
Output current ....................................4.5 A
Output 2:
Output voltage ................................ 21.5 V
Output current ....................................4.5 A
Charging time
We recommend that you only use
this charger to charge the following
rechargeable batteries:PAP 20 B1,
PAP 20 B3, Smart PAPS 204 A1,
Smart PAPS 208 A1
Charging time (min.) PDSLG 20 B1
PAP 20 A1
PAP 20 B1
PAP 20 A2
PAP 20 A3
PAP 20 B3
Smart PAPS 204 A1
Smart PAPS 208 A1
The charging time is influenced by factors
such as the temperature of the ­environ-
ment and the battery, as well as the mains
voltage applied, and may ­therefore devi-
ate from the specified values.
Safety Warnings
ATTENTION! When
using power tools,
observe the follow-
ing basic safety
measures to pro-
tect against electric
shock, risk of injury
and fire.
This device can be used by chil-
dren aged 8 years and up as
well as individuals with reduced
physical, sensory or mental abil-
35
45
60
120
