5. Anhang
5.1. Anhang A:
1. [en] Loads which can be controlled directly by the Load disconnect output of the Smart BMS:
• [en] Inverters:
[en] All Phoenix inverters VE.Direct and Phoenix Inverters Smart. Connect the Load disconnect output of the BMS to
terminal H of the 2-pole connector of the inverter.
• [en] DC-DC converters:
[en] All Tr type DC-DC converters with remote on/off connector and Orion 12/24-20. Connect the Load disconnect output of
the BMS to the right hand terminal of the 2-pole connector.
• [en] BatteryProtect and Smart BatteryProtect:
[en] Connect the Load disconnect output of the BMS to terminal 2.1 (right hand terminal) for the BatteryProtect and H pin
of the 2-pole connectorfor the Smart BatteryProtect.
• [en] Cyrix-Li-Load:
[en] Connect the Load disconnect output of the BMS to the control input of the Cyrix.
2. [en] Loads for which an inverting remote on-off cable
• [en] Phoenix VE.Bus inverters and VE.Bus Inverter Compact rated at 1200VA or more
3. [en] Solar charge controllers which can be controlled directly by the Charge disconnect output:
• [en] BlueSolar MPPT 150/70 and 150/80 CAN-bus:
[en] Connect the Charge disconnect output of the BMS to the left hand terminal of the 2-pole connector (B+).
• [en] SmartSolar MPPT 150/45 and higher, 250/60 and higher
[en] Connect the Charge disconnect output of the BMS to the right hand terminal (marked +) or the left hand terminal
(marked H) of the 2-pole connector.
4. [en] Solar charge controllers for which a
ASS030550320):
• [en] BlueSolar MPPT models except the BlueSolar MPPT 150/70 and 150/80 CAN-bus
• [en] SmartSolar MPPT up to 150/35
5. [en] Battery Chargers:
• [en] Phoenix Smart IP43 Chargers:
[en] Connect the Charge disconnect output of the BMS to terminal H of the 2-pole connector.
• [en] Skylla TG battery chargers:
[en] Use a non-inverting remote on-off cable
• [en] Skylla-i battery chargers:
[en] Use a Skylla-i remote on-off cable
• [en] Other battery chargers:
[en] Use a Cyrix-Li-Charge or connect the charger to the primary side of the Smart BMS.
6. [en] MultiPlus:
• [en] MultiPlus 500VA – 1600VA & MultiPlus Compact 800VA – 2kVA
[en] If these MultiPlus models are not connected directly to the System+ port, they can also be controlled from the Load
disconnect and Charge disconnect outputs by using the
ASS070200100). This cable must be wired to the remote on/off connector of the MultiPlus.
Seite 11
Smart BMS 12-200
is needed (article number ASS030550100 or -120):
VE.Direct non-inverting remote on-off cable
(article number ASS030550200).
(article number ASS030550400).
Smart BMS CL 12-100 to MultiPlus cable
is needed (article number
(article number
