5.3. [en] Appendix C
[en] LED indicators (from left to right)
1. [en] Green: Alternator charging
2. [en] Red: Over-Temperature protection of the Smart BMS
3. [en] Green: Smart BMS is active
4. [en] Blue: blinking – Bluetooth broadcasting, ON – connection established
5. [en] Yellow: Charge disconnect output is enabled
6. [en] Orange: Load disconnect output is enabled
7. [en] Green: Charging from System+ port enabled
1
2
Seite 15
Smart BMS 12-200
3 5
7
4 6
Anhang
