Incorrect installation can put
• your own life at risk;
• and the lives of other users of the
electrical system.
Incorrect installation also means that
you are running the risk of serious
damage to property, e.g. because of a
fire. You may be personally liable in the
event of injuries or damage to proper-
ty.
Contact an electrical installer!
*Specialist knowledge required for ins-
tallation:
The following specialist knowledge is
particularly important during installati-
on:
• The "5 safety rules" to be used:
Disconnect from mains; Safeguard
from switching on again; Check
that system is deenergised; Earth
and short circuit; Cover or cordon
off neighbouring live parts;
• Select suitable tool, measuring
equipment and, if necessary, per-
sonal safety equipment;
• Evaluation of measuring results;
• Selection of electrical installation
material for safeguarding shut-off
conditions;
• IP protection types;
• Installation of electrical installation
material;
• Type of supply network (TN sys-
tem, IT system, TT system) and the
resulting connecting conditions
(classical zero balancing, protective
earthing, required additional mea-
sures etc.).
Installation may only take place in
normal commercial switch boxes
(device boxes) in accordance with
DIN 49073-1 or surface-mounting
boxes in accordance with DIN
60670-1 (e.g. Abox 025 or Abox
040).
Please observe the hazard infor-
mation in section
information" on page 15)
ring installation. or surface-moun-
ting boxes in accordance with DIN
60670-1 (e.g. Abox 025 or Abox
040).
Permitted cable cross sections for con-
necting to the blind actuator are:
rigid cable flexible cable with/wit-
[mm²] hout ferrule [mm²]
0.75 - 1.50 0.75 - 1.50
6.2

Installation

You can install the blind actuator
• in a flush-mounting box or
• in a surface-mounting box

6.2.1 Flush-mounting box installation

To install the blind actuator in a flush-
mounting box, please proceed as fol-
lows:
• Switch off the fuse of the power
circuit
• Connect the switched phase con-
ductors for connecting terminals 1
and 2 to the motor as follows:
- Connecting terminal 2 (C): "Up"
- Connecting terminal 1 (D):
"Down"
• Connect the phase conductor to
connecting terminal L (E)
• Connect the neutral conductor to
connecting terminal N (F)
(see „3 Hazard
du-
