Siko AP05 Zusatz Zur Originalmontageanleitung Seite 35

AP05-SW06
Service-Standard-Protocol
Parameter: no Parity, 8 Bit, 1 Startbit, 1 Stoppbit
SIKONETZ 3: baud rate 19200
SIKONETZ 4: baud rate 115200
Generally, transmission occurs as follows: The control (PC) sends a letter
(ASCII), with additional parameters if required. Subsequently, the AP05
sends a response with a concluding CR (0x0D). Small letters and capitals
are accepted equally (ASCII).
List of commands
Com- Access Data
mand
A0 read
A1 read
B read
C
D
E0 read
E1 read
E2 read
E3 read
E4 read
E5 read
E6 read
E7 read
E8 read
F1 write "+/-xxxxxxxx" 9/1
F2 write "+/-xxxxxxxx" 9/1
F5 write "+/-xxxxxxxx" 9/1
F6 write "+/-xxxxxxxx" 9/1
F7 write "+/-xxxxxxxx" 9/1
F8 write "+/-xxxxxxxx" 9/1
G
H
lab write "1x"
write "0x"
write "x1"
write "x0"
AP05-SW06 · Date 01.03.2018 · Art. No. 89532 · Mod. status 49/18
Data Response
quantity
2/7 "HWVxxxx>" Hardware version number
2/7 "SWVxxxx>"
1/10 "+xxxxxxxx>" Position value without correc-
x/1 "?"
x/1 "?"
2/10 "+xxxxxxxx>" Position value
2/10 "+xxxxxxxx>" Calibration value
2/10 "+xxxxxxxx>" Offset
2/10 "+xxxxxxxx>" Incremental measurement
2/10 "+xxxxxxxx>" Position value with zeroing
2/10 "+xxxxxxxx>" InPos window
2/10 "+xxxxxxxx>" Reversal point for loop
2/10 "+xxxxxxxx>" Display per revolution
2/10 "+xxxxxxxx>" Display divisor
">"
">"
">"
">"
">"
">"
x/1 "?"
x/1 "?"
3/1 ">"
3/1 ">"
3/1 ">"
3/1 ">"
Meaning
Software version number
tion values
Calibration value
Offset
InPos window
Reversal point for loop
APU
ADI
a = 1: enable zeroing
a = 0: disabled zeroing
b = 1: enabled incremental
measur. setting
b = 0: disabled increm. measur.
setting
English 35
Example
V002
V006
+00000016
+00000023
+00000004
+00000003
+00000000
+00000000
+00000005
+00000000
+00000720
+00000001
F1+00000004
F2+00000003
F5+00000005
F6+00000000
F7+00000720
F8+00000003
I11
I01
I11
I10
