SIKONETZ 4

Reset position value to 0 + calibration value + offset value (ID 1)
81h 48h C9h
Program mode "OFF" (ID 1)
81h 33h B2h
Write target value 123 (ID 1)
01h 20h 7Bh 00h 00h 5Ah
8 SIKONETZ 4
Bus protocol for up to 31 subscribers.
Parameter: 115200 baud, EVEN parity, 8 Bit, 1 Stoppbit, no handshake.
The data telegram consists always of 5 bytes:
1. byte : status/ address.
2. byte : data byte A
3. byte : data byte B
4. byte : data byte C
5. byte : check sum

8.1 Status-/ adresse

This byte defines the type of telegram to be transmitted, e. g., whether
the configuration of the AP05 is to be changed or only the position value
read out. The AP05 responds only to messages with the matching device
address.
AP05-SW06 · Date 01.03.2018 · Art. No. 89532 · Mod. status 49/18
XOR checksum
Value = 123
Command write target value
Length bit (00h) UND ID 1
