ACCESSORIES
1
a
2
3
More accessories see „Window panel installation"
1
2
3
4
5
6
7
8
Installation of cable hooks
1.
b
c
4
6
5
2.
1
2
3
4
5
6
6
9
1
2
3
4
5
6
7
8
Fix the cable hooks to the fixating points with
the screws as shown in picture 1.
Wind the power cable around the cable hooks
as shown in picture 2.
44
Joint parts a and b and c
2x Cable hooks
3x Screws
Drain hose adapter
Pipe hoop
Heat discharge pipe
Filter cover
Air inlet
Middle drainage port
Fixing clasp
Groove for
heat discharge pipe
Fixing points for
cable fixing hooks
Fixing point for
drainage pipe clip
Lower drainage port
