CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuse-holder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuse-holder.
Step 3: Install the new fuse in the fuse-holder.
Step 4: Replace the fuse-holder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Number of DMX channels:
DMX512 connection:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
state):
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
LED type:
Number of LEDs:
Beam angle:
Dimensions (LxWxH):
Weight:
Accessories:
TPC-10 Coupler, silver
Safety bond AG-5 3x600mm up to 5kg
DMX cable XLR 3pin 5m bl
DMX cable XLR 3pin 5m bk Neutrik
DMX cable XLR 3pin 5m bk Hicon
DMX cable XLR 3pin 5m bk Neutrik
Please note: All information is subject to change without prior notice. 18.12.2015
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady
C
100-240 V AC, 50/60 Hz ~
70 W
8
3-pin XLR
via built-in microphone
45° C
70° C
0.5 m
0.1 m
F 2 A, 250 V
RGBW 4in1
9
30°
100 x 285 x 260 mm
1.6 kg
No.
59006856
58010360
3022785K
30227812
30307458
30307471
23/24
00095610.DOC, Version 1.0
©
