Abbreviation Explanation
STEL Short time exposure limit, threshold of an exposition
over a short period of time (generally 15 minutes).
TWA Time weighted average, average shift values are gen-
erally limited to eight hours exposure per day per work-
place for 5 days a week during a work lifetime. Observe
the national definition of the occupational exposure
limit.
3

Description

3.1

Product overview

The graphics are shown on the fold-out page in figure A.
1 Alarm LED
2 Gas entry
3 Display
4
-key
5 -key
OK
6 Buzzer
7 IR interface
3.2

Symbol explanations

Symbol Explanation
Fault massage
Warning message
Display peak value
Show TWA
Instructions for use |
X-am
8 Fastening clip
9 Type plate
10 Power pack
11 Charging contacts
12 Measured gas display
13 Measured value display
14 Special symbols
®
5100 Cyanogen
Symbol Explanation
Show STEL
Bump test mode
Fresh air calibration
1-button sensitivity adjustment
Standard sensitivity adjustment
Password required
Battery 100 % full
Battery 2/3 full
Battery 1/3 full
Battery empty
3.3

Intended Use

Portable single gas detection instrument for the continuous monitoring of the
concentration of C N in the ambient air within the working area.
2 2
3.4

Approvals

The approvals are shown on the type plate. The type plate on the gas meter
must not be pasted over.
4

Use

4.1

Preparations for operation

Prerequisites
– Before using the instrument for the first time, the enclosed batteries or a
charged T4 NiMH power pack (Order No. 83 18 704/83 22 244) must be
inserted (see "Replacing the batteries/rechargeable batteries", page 24).
| en
Description
17
