Tietzsch MultiSafe TT 3 Bedienungsanleitung Seite 12

1
2
3
4
5
7
8
TT 3K
Art.-no. 89337
6
6
1. Test electrode
2. Red limiting mark
3. Locking for pull-out
4. Type plate
5. Limiting disc
6. Handgear
7. Display part
8. Contact magnet or
contact clamp or
universal clamp
360° LED indication red / green
Symbols on the instrument
Attention! Observe user instructions!
EC conformity
Device for live working
This device has to be disposed of according to the
applicable regulations and laws
(for Europe: WEEE 2012/19/EU).
Please contact service@tietzsch.de in regard to the
return of old devices.
2
red -LED for Voltage
green LED for Test and
Absence of voltage
Display (LCD)
Frequency / DC
Voltage value
