Security
Security (Kensington® Type) Lock Slot
BIOS Password
(Factory Option) TPM 2.0
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
1.0M HD Webcam
Or
(Factory Option) 2.0M FHD Webcam with
TNR
Or
(Factory Option) Dual Sensor 2.0M FHD
Windows Hello Webcam with TNR with
SecureBIO
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wi-Fi
6E AX211, 2x2 Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6
AX201, 2x2 Wireless LAN + Bluetooth
(Factory Option) Intel® Tri-Band Wi-Fi 7
BE200, 2x2 Wireless LAN + Bluetooth
Card Reader
MicroSD Card Reader
M.2 Slots
Slot 1 for WLAN and Bluetooth Combo
Module
Slot 2 for PCIe Gen4 x4 SSD
(Model B Only) Slot 3 for PCIe Gen4 x4
SSD
Interface
One USB 3.2 Gen 1 Type-A Port
One Powered USB 3.2 Gen 2 Type-A Port
One DisplayPort 1.4 over USB 3.2 Gen 2
Type-C Port*
*The maximum amount of current supplied
by USB Type-C ports is 500mA (USB 2.0)/
900mA (USB3.2).
One Thunderbolt 4 Port with Power Delivery
(DC-In)
One HDMI-Out Port
One 2-In-1 Audio Jack (Headphone / Micro-
phone)
One RJ-45 LAN Jack
One DC-In Jack
Features
Virtual Reality Ready
Design II Only
X-Rite™ Pantone® Color Calibration
Certified
NVIDIA® Studio
Environmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 20V, 9A (180W)
Embedded 4 Cell Polymer Battery Pack,
80WH
Dimensions & Weight
Model A
317mm (w) * 235mm (d) * 19.9mm (h)
1.69g (Barebone with 80WH Battery)
Model B
358mm (w) * 258.6mm (d) * 19.9mm (h)
1.95kg (Barebone with 80WH Battery)
