System Map: Front View with Display Open (Model B)

Figure 3
Front View with Display Open (Model B)
1. Built-in Webcam*
Or
(Factory Option) Windows Hello Webcam*
*When the webcam is in use, the LED (next to the
webcam) will be illuminated.
2. Built-In Array Microphone
3. Display
4. Power Button
5. Keyboard
6. Touchpad & Buttons
Note that the Touchpad and Buttons
valid operational area is that indicat-
ed within the dotted lines above.
8
6
2 1 2
3
16" (40.64cm)
5
6
4
