System Map: Front View with Display Open (Model A)

2 1 2
3
14" (35.67cm)
5
6
Front View with Display Open (Model A)
1. Built-in Webcam*
Or
(Factory Option) Windows Hello Webcam*
*When the webcam is in use, the LED (next to
the webcam) will be illuminated.
2. Built-In Array Microphone
3. Display
4. Power Button
5. Keyboard
6. Touchpad & Buttons
4
Note that the Touchpad and
Buttons
area is that indicated within
the dotted lines above.
Figure 2
6
