Mapa do sistema: Vistas frontal, esquerda e direita (Modelo A)
System Map: Front, Left & Right Views (Model A)
7
Reaquecimento Overheating
Para evitar que o seu compu-
To prevent your comput-
tador sobreaqueça certifi-
er from overheating
que-se de que nada bloqueie
make sure nothing
a(s) grelha(s) com o
blocks any vent while the
aparelho ligado.
computer is in use.
160 10
Parte frontal
Front
2
3
Lateral esquerda Left
8 9
10
Lateral direita
Right
Figura 3 - Vistas frontal, esquerda e direita (Modelo A) Figure 3 - Front, Left & Right Views (Model A)
1. LED Indicators
2. Vent
1. LED Indicators
3. USB 3.2 Gen 1 Type-A Port
2. Security Lock Slot 3. Vent
4. *Powered USB 3.2 Gen 1 Type-A
4. MicroSD Card Reader
Port
5. USB 3.2 Gen 1 Type-A Port
*Toggle power to this port by
6. 2-In-1 Audio Jack (Headphone / Microphone) 7. Speakers
using Fn + Power Button (see
8. DisplayPort 1.4 over USB 3.2 Gen 2 Type-C Port 9. Thunderbolt 4 Port with Power
Table 2 on page 8).
Delivery (DC-In)* 10. Powered USB 3.2 Gen 2 Type-A Port (see page 9) 11. DC-In Jack
5. 2-In-1 Audio Jack (Headphone /
*The port with Power Delivery DC-In function allows you to use a power source, with a
Microphone) - see page 19
USB Type-C cable and connector, plugged into the port to charge the computer. Make
6. 2-In-1 Audio Jack (Microphone /
sure any power source is appropraitely certified, and complies with the USB-C PD (Power
S/PDIF Optical) - see
page 19
Delivery) standard specification rated at 20V, 5A or 20V, 3.25A (for off mode charge).
7. Speakers
5 6
4
7
2
8. MicroSD Card Reader
9. DisplayPort 1.4 over USB 3.2 Gen 2 Type-C Port
10. Thunderbolt 4 Port with Power Delivery (DC-In)*
*This port allows you to use a third party AC/DC
adapter/power bank plugged into the port as a
power supply. If you are using a power bank make
sure that it complies with the USB-C PD (Power
Delivery) standard specification (20V/65W - 20V/
100W). If you are using a third party AC/DC
adapter, the rating of the adapter must be 20V/65W
- 20V/100W and it should be appropriately certified.
