BVS ID-M1280xF1-xx-xxx
7.6

Selecting the data interface for the process data

The exchange of the process data (results of image analysis, control of image acquisition, ...) are exchanged via
IO-Link or LAN interface. The data are transferred as TCP or UDP packets via the LAN interface.
→ The operating principle and data protocol of the IO-Link or the TCP/UDP protocol are described in the
separate configuration guide in the chapter Connection to the customer control system.
You can change the data the following way:
1.
Connect to the sensor via PC and a web browser.
2.
Open the System settings.
3.
Choose the right Protocol in the tab Communication:
Available options for the selection are IO-Link, TCP and UDP. If TCP or UDP is selected, the camera uses port
36701. The controlling system can use any available port.
Interfaces that are not selected are deactivated!
english
37
