Wiring Diagram - Bergstrom SLIM FIT Montageanweisungen

SLIM FIT
Take care not to invert polarities when connecting the unit. If this happens, the plate does not come on and
the unit does not work.
Centrifugal
blower
2,6 Amp.
Az Blue
Black
N
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Compressor
electronic
module
Compressor
IMPORTANT NOTE!
Electronic
board
Authorized connection
or battery
21
Return
air sensor
NTC 15KΩ a 25º
Comsuption 30 mAmp.
2,9 Amp.
PWM.
Condenser
fan
Compressor
electronic
module
Compressor
EN

Wiring diagram
