OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. You can move through the main menu by turning the encoder. Press the encoder to select the desired
menu item. You can change the selection by turning the encoder. Confirm each change by pressing the
encoder. The respective mode can be exited via the "Quit" menu item. The respective functions are
described below. All settings remain stored even if the device is disconnected from the mains. The device
can be operated either in standalone mode via the encoder or in DMX-controlled mode via a commercially
available DMX controller.
Encoder:
Selects the operating mode
Activates a value to be modified or saves a value when modifying.

Menu structure

Default setting shaded:
Display
DMXAddress
DIM
Curve
Mode
PWMrate

Stand Alone-Mode

The respective mode can be exited via the "Quit" menu item.
DIM
Intensity
In Intensity mode, you can set the total brightness.
Press the encoder and then turn the encoder until the Intensity function is indicated in the display. Confirm
by pressing the encoder. Now you can set the desired brightness from 000 – 255 by turning the encoder.
Confirm by pressing the encoder.
Strobe
In Strobe mode, you can set the speed for strobe.
Press the encoder and then turn the encoder until the Strobe function is indicated in the display. Confirm by
pressing the encoder. Now you can set the desired speed from 000 – 012. Confirm by pressing the encoder.
A001 Setting the DMX starting address A001 – A512
Intensity Setting the total brightness 000 – 255
Strobe Setting the strobe speed 000 – 012 (increasing)
Setting the dimmer curves
Dimmer curve 1: Linear;
Curve Dimmer curve 2: Exponential;
Dimmer curve 3: Logarythmic;
Dimmer curve 4: S-type
1CH Setting the 1-channel mode
2CH Setting the 2-channel mode
Pulse-width modulation
With this function the PWM frequency of the LEDs can be
PWMrate
set: 800Hz, 1200Hz, 2000Hz, 3600Hz, 12000Hz,
15000Hz, 25000Hz
Function
