M E T R O 1 00 - I N S TA L L AT I O N M A N UA L
Table 2: Determination of th e permissibility of a concentric system with a roof terminal
G20 / G25
no bends
2 bends
→
3 bends
→
4 bends
5 bochten
■
■
= situation is not allowed
G20 / G25
Situation
A
B
C
6.5.3.2 Placing concentric system with roof terminal
The roof terminal can end in a sloping and a fl at roof.
The roof terminal can be supplied with an adhesive plate for a fl at roof or with a universally adjustable tile for a
sloping roof.
- Maintain a distance of at least 50 mm between the outside of the concentric system and the walls and/or the ceiling.
Caution
If the system is built in (for instance) a cove, it should be made with non combustible material all around it;
- Use heat-resistant insulation material when passing through combustible material.
!Caution Some heat-resistant insulation materials contain volatile components that will spread an unpleasant smell for a pro-
longed time; these are not suitable.
Place the concentric system as follows:
➠
Build the system up from (the connection stump of) the appliance.
➠
Connect the concentric pipe pieces and, if necessary, the bends.
➠
On each connection, apply a clip binding with silicon sealing ring.
➠
Use a self-tapping screw to fi x the clip binding to the pipe on locations that cannot be reached after installation.
