M E T R O 1 00 - I N S TA L L AT I O N M A N UA L
Appendix 1 Parts included with t he delivery
In the following table you can fi nd the parts that are supplied with the appliance.
Part
Wood/pebble set
Control box
Manual control box
Installation manual
User manual
Decorative strip left
Decorative strip right
Decorative strip below
Template for baffl e
Baffl e
Key bolts M8x 140x50
Hexagonal nut M8
Washer 8.4 mm
Spare self-tapping screws for mounting the glass window
Socket spanner 8 mm
Remote control with receiver
9V block battery
Penlite battery (AA type)
Pressure coupling 15 mm x G3/8"

Appendix 2 Technical data

In the following table you can fi nd the technical data of the Metro 100/Metro 100 tunnel.
Type
Type of gas
Burner pressure
Nominal heat input (Hs)
Nominal heat input (Hi)
Nominal output
Consumption
Burner injector
Consumption on low output
Low setting injector
Pilot burner injector
Effi ciency class
95900005_ML1 Install.indd 19 95900005_ML1 Install.indd 19
Table 5: Parts included with the del ivery
Quantity
1x
1x
1x
1x
1x
Metro 100 1x / Metro 100 tunnel 2x
Metro 100 1x / Metro 100 tunnel 2x
Metro 100 1x / Metro 100 tunnel 2x
1x
1x
2x
4x
4x
1x
1x
1x
4x
1x
Table 6: Technical data
C11/C31
G25
mbar 19
kW 9.3
kW 8.4
kW 6.5
L/h 992
mm 3x Ø 1.40
L/h 502
mm Ø 1.80
Kode 51
2
G20
18
9.3
8.4
6.5
870
3x Ø 1.30
462
Ø 1.80
51
2
1 9 GB
