7.

Wireless remote control

The appliance is supplied with a wireless remote control.
Ignition, controlling the fl ame height and swit ching off are performed by a remote control that operates a receiver
in the control box.
User Manual, chapter 4, Wireless Remote Control, describes the operation of the appliance including the way the
remote control works.
Do not ignite the appliance until it is fully installed.
Caution
Below, we will describe how the receiver is con nected.

7.1 Receiver

The receiver should be connected to the appliance, before the batteries are installed.
Follow the procedure below (see fi g. 19):
➠
Slide the brown plug of the connecting cable onto the back of the receiver's printed circuit board.
➠
Connect the white plug to the gas control.
!Tip The plugs have diff erent sizes that correspond with the connectors.
➠
Connect the cables of the thermocouple to the receiver; (see fi g. 19, arrow B)
!Tip - The size of the eye corresponds with the size of the screw;
- The colours of eye and screw also correspond.
➠
Connect the ignition cable to the receiver; (see fi g. 19, arrow A)
➠
Connect power:
a) When using batteries, see section 7.1.1 below;
b) When using an adapter:
-
-
➠
Place the receiver (V) in the control box, as indicated on fi g. 20.
➠
Bend the antenna out of the clips; see fi g. 19, arrow D.
➠
Set the antenna straight.
!Caution - Do not place the antenna (N) too close to the ignition cable and/or metal parts (for the correct position, see fi g. 20);
- Do not place the ignition cable over and/or along metal parts: this will weaken the spark;
- Do not lay the ignition cable over the receiver: this could damage the receiver;
- Avoid dust on or in the receiver: cover it when perf orming work.
7.1.1 Placing / replacing the batteries
Follow the procedure below when placing the batteries:
➠
Open the door of the control box.
➠
Pick up the receiver.
➠
Slide the cover off .
➠
Place or remove the 4 penlite (AA type) batteries.
!Caution - Avoid a short circuit between the batteries and metal objects/parts;
- Observe the "+" and "-" poles of the batteries and the holder;
- Use alkaline batteries.
➠
Slide back the cover.
➠
Place back the receiver.
!Caution Batteries are regarded as "small chemical wa ste" and may therefore not be disposed with the household rubbish.
GB 1 4
95900005_ML1 Install.indd 14 95900005_ML1 Install.indd 14
connect it to the receiver; (see fi g. 19, arrow C);
insert the plug into the wall socket.
