M E T R O 1 00 - I N S TA L L AT I O N M A N UA L
6.10 Glass win dow
After placing the wood/pebble set you can plac e the glass window, as described below.
!Caution Avoid damages when removing/placing the glass window.
6.10.1 Removing the glass window
Remove the gl ass window in accordance with the following instructions (see fi g. 18a up to 18l):
➠
Remove the vertical decorative strips on the left and right of the glass window by pushing the lip at the top of each
strip up, tilting the top of the strip parallel with the glass window, and then removing the strip.
➠
Remove the horizontal decorative strip by gripping it with 2 hands in the slot and lifting it out.
➠
Unscrew the 4 self-tapping screws in the bottom strip using the socket spanner supplied with the appliance.
➠
Loosen the 3 self-tapping screws in the fastening strips on both sides 2 turns.
!Caution Do not remove the self-tapping screws: leave them in place in the fastening strips.
➠
Push the 2 top wedges (left and right) down as far as possible.
➠
Push the 2 bottom wedges upwards as far as possible.
➠
Press the two fastening strips outwards with your hands as far as possible to avoid damage to the sealing cord when
removing the glass window.
➠
Take hold of the top and bottom handgrips and lift the glass window.
➠
Pull on the bottom handgrip to tilt the glass window in its mounting towards you and, at the same time, pull the top of
the glass window towards you as far as possible.
!Caution - Firmly hold the upper grip. If you let go of the handgrip then the glass window could fall inwards and cause severe
damage to both the glass and the appliance;
- Make sure that you lift the glass window out of its mounting as straight as possible to avoid damage to the paint-
work and the sealing cord.
➠
Gently allow the glass window to drop at an angle until it can be removed entirely from the mounting.
6.10.2 Placing the glass window
The glass window is fi tted by using the above procedure, in reverse order.
!Caution - Avoid/remove fi ngerprints on the pane, since otherwise they will burn into the surface;
- The self-tapping screws must not be over-tightened, since otherwise they could break or strip the thread: tight=tight;
- Replace the fastening strip if the sealing cord has come loose.
Pay attention to the following when fi tting the glass window:
➠
Begin by checking that the two fastening strips are pressed outwards as far as possible to avoid damage to the sealing
cord, when placing the glass window.
➠
Fit the glass window.
➠
Check that the hook at the top of the glass window is in position in the seating / U-shaped strip.
!Tip Pull on the upper handgrip to move the glass frame towards you: if it does not move, then it has been fi tted correctly.
!Caution Fix the glass window's bottom strip in place with the 4 self-tapping screws.
➠
Push both bottom wedges downwards.
➠
Push the top wedges upwards until both fastening strips and sealing cords press against the pane.
➠
Tighten each wedge's self-tapping screw.
!Caution Press on the wedge with your hand to hold it in place while you tighten the screws.
➠
Tighten the middle self-tapping screw in each fastening strip.
➠
Fit the horizontal decorative strip.
➠
Fit the vertical decorative strips.
