Focus
Step 1: Loosen the focus fixation screws on both sides of the device.
Step 2: Adjust the focus by sliding the lens-housing forward or backward.
Step 3: Tighten the focus fixation screws on both sides of the device.
Zoom
Step 1: Loosen the zoom fixation screws on both sides of the device.
Step 2: Adjust the zoom by sliding the lens-housing forward or backward.
Step 3: Tighten the zoom fixation screws on both sides of the device.
Please note: When setting the focus or zoom, always adjust on both sides of the unit. One-sided adjusting
could lead to a misalignment in the guide grooves.

DMX MODE

You can control the devices individually via your DMX-controller.
Addressing
The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the device will respond to the controller.
Press the MODE button until the display shows „DMX512". Press ENTER to confirm.
You can now set the desired address via the UP or DOWN buttons. Press ENTER once again to confirm.
Press the MODE button in order to return to the main menu.
Please, be sure that you don't have any overlapping channels in order to control each device correctly and
independently from any other fixture on the DMX-chain.
If several devices are addressed similarly, they will work synchronically.
Controlling:
After having addressed EUROLITE LED PFE-100 RGBW Profile Spot, you may now start operating it via
your lighting controller.
Note:
After switching on, the device will automatically detect whether DMX 512 data is received or not. If the data
is received, the LC display lights up permanently.
If there is no data received at the DMX-input, the LC display will flash.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the device.
- the controller is switched off or defective,
- the cable or connector is defective or the signal wires are not properly connected with the input connector.

DMX-protocol

Channel 1 – Red
Value :
000 – 255
Channel 2 – Green
Value :
000 – 255
Channel 3 – Blue
Value :
000 – 255
Function:
0 – 100 %
Function:
0 – 100 %
Function:
0 – 100 %
