Dometic POWER & CONTROL CAM360AHDHD Montage- Und Bedienungsanleitung Seite 18

Item
8
9
10
11
12
bn
bu
pk
wh
ye
bk
rd
ye
5. Test the video system by performing a calibration test (see
6. Mark the positions of the cameras.
7. Remove the tape and the cameras.
7.4 Fastening the cameras
2. Drill a hole of ⌀ 20 mm for the cable entries.
1. Center-punch the previously marked points to prevent the drill head from slipping.
Fig.  on page 6
3. Feed the camera cable into the vehicle interior.
Fig.  on page 6
4. Mark the holes for the mounting screws.
Fig.  on page 7
5. Remove the camera.
16
Description
Black plug ("Le CAM"): Le camera
Black plug ("Right CAM"): Right camera
Black plug ("Rear CAM"): Rear camera
IR receiver
Controller
Brown trigger cable ("TRIG_WARD"): Connection to the positive cable of the reversing light.
When the reverse gear is engaged, the controller and the rear camera are activated via this ca-
ble.
Blue trigger cable ("TRIG_EXTEND"): Control signal input for displaying the bird's eye view in
full screen (12 V signal).
Pink trigger cable: Control signal output for switching on a monitor (12 V signal).
White trigger cable ("TRIG_L"): Connection to the positive cable of the le indicator.
When the le indicator is activated, the controller and the corresponding camera are activated
via this cable.
Yellow trigger cable ("TRIG_R"): Connection to the positive cable of the right indicator.
When the right indicator is activated, the controller and the corresponding camera are activat-
ed via this cable.
Black cable ("GND"): Connection to earth (terminal 31)
Red cable ("DC 12–32V"): Connection to continuous battery positive (terminal 30). Enables
amongst others saving of date and time (recorder function).
Yellow cable ("ACC"): Connection to the ACC ignition (terminal 15).
Calibrating the video system).
