NOTICE! Damage hazard
• To prevent damage when drilling ensure that there is sufficient space on the other side for
the drill head to emerge.
• Deburr all drill holes and treat them with a rust-protection agent.
• When working on the electrical system, the batteries must be separated from the vehicle
ground. This applies to the main and additional batteries.
• When working on the following cables only use insulated cable lugs, plugs and tab sleeves:
Do not use porcelain wire connectors.
• Use a crimping tool to connect the cables.
• Screw the cable when connecting cable 31 (ground).
Ensure that there is a good ground connection.
• If the battery is disconnected, all data stored in all volatile memory will be lost. Data may
have to be reset. Follow the instructions of the vehicle manufacturer in this case. The instruc-
tions for making these settings can be found in the operating manual.
• When testing the voltage in electrical cables only use a diode test lamp or a voltmeter. Test
lamps with a bulb consume too much voltage which can damage the vehicle's electronic
system.
• When making electrical connections ensure the following:
• Insulate all connections.
• Secure the cables against mechanical stress with cable binders or insulating tape, e.g., to
existing lines.
• Follow the installation and operating manual for the monitor.
• Do not open the camera.
• Do not pull the cables.
• Do not expose the cables to solvents such as benzene for long periods of time.
• Do not use the cameras under water.
• Install cables far enough away from hot or moving vehicle parts (exhaust pipes, drive shas
exhaust pipes, drive shas, lights, blowers, heaters, etc.).
5

Intended use

The video system is intented for use in vehicles. The cameras transmit images in a 360 ° panoramic view that pro-
vides a view of the vehicle's environment to the sides, in front, and behind.
12
30 (direct input from positive battery terminal)
15 (connected positive terminal, behind the battery)
31 (return cable from the battery, ground)
58 (reversing light)
Screw the cable using a cable lug and lock washer to one of the vehicle's ground
bolts or
Screw the cable to the sheet metal body work using a cable lug and a self-tapping
screw.
They are not kinked or twisted.
They do not rub on edges.
They are not laid in sharp-edged through-holes without protection.
