emergency occur. You personally assume all the risks and responsibilities for your actions and decisions: if
you are not able or not in a position to assume these, do not use this equipment.
3 YEAR WARRANTY
This product is warranted against any faults in materials or manufacture for 3 years from the purchase date.
INSTRUCTIONS FOR USE
Summary
C.A.M.P. Gyro3 is a device designed to connect two, three or four elements between each other, which need
points of EN 795:2012 and EN 354:2010. Gyro3 is also tested according to the American ANSI / ASSP Z359.12-2019
standard. By way of non-exhaustive example, some applications are: multi-anchorage with self-orientable points,
multiple harness connections, anti-twist function for lanyards, cross-hauling operations, tyrolean traverses, rescue
operations. This product is intended for use to protect and prevent against the risk of falling from a height in rescue
operations, in work at a height, in the practice of mountaineering, rock-climbing and other vertical sports that use
similar techniques.
Use
Gyro3 must be connected to other elements of the system through compatible connectors inserted in the
attachment holes [2a] (
for mountaineering use; in the case of permanent connections, select by preference quick links (Class Q). Avoid
transverse stresses on the connectors (
( ). Use only C.A.M.P. anti-rotation inserts. Alternatively, it is possible to directly connect a rope (EN 1891 or EN
892) or webbing (EN 565) knotted inside the attachment holes [2a], in this case removing the anti-rotation insert
[3] ( ). The maximum applicable load (WLL) is 500 kg (~5 kN). The breaking load (MBL) is 26 kN. The maximum
could compromise its strength. (
of force direction. Do not stay above the anchor point: risk of failure/injuries in case of fall. Take measures to avoid
pendulum. Gyro3 should not be used alone as a fall arrest component. Gyro3 can be used in a fall arrest system
when combined with an EN 355 energy absorber and EN 362 connectors; in this case the maximum length of the
string-Gyro3-absorber-connector system must never exceed 2 m and must be connected to the attachment element
(A) of a EN 361 full body harness. The length of the device should be taken into account when used in any fall arrest

CHECKING AND MAINTENANCE

Check the correct rotation of the swivel balls [2] at each use in case of dirt, clean with a blast of compressed air and/
or immerse in fresh water and subsequently dry in a ventilated environment. After cleaning, the mechanism can be
lubricated. Cleaning and lubrication are recommended after each use in a marine environment.

PERIODIC INSPECTION

visual inspection prior to, during, and after use, this product must be inspected by a competent person at least once
every 12 months. This frequency should be increased if the equipment is used by multiple individuals or if subject

SPECIFIC INFORMATION

). Use EN 362 class B or ANSI Z359.12 connectors for industrial use or EN 12275
), preferring the use of the appropriate anti-rotation inserts [3]
). Prevent Gyro3 from hitting uneven surfaces or sharp edges that
. If used in a fall arrest system, the system must limit the peak force below 6
Use adequate rescue equipment and provide adequate training
