Possible combinations

Outside
Reader module
open with battery and
control unit
Reader module cover
Fig. 2

Features

• Quick and easy installation.
• No drilling and no cables required.
• Suitable for all DIN locks.
• Easy programming.
• Battery operated (battery service life approx. 2 years).
Cylinder adapter
EPC Electronic Profile Cylinder - Status 05.2008 - 732.29.490
Installation and Operating Instructions
Inside
Knob
or
reader module
