3.4.4 Abmessungen

- R10..20DQ
DN
10
15
20
- R10..20EQ
DN
10
15
20
l1
l2
D [Zoll] d2 [Zoll]
Rp3/8 R3/8
Rp1/2 R1/2
Rp3/4 R3/4
D
l3
l4
D [Zoll] d2 [Zoll]
Rp3/8 R3/8
Rp1/2 R1/2
Rp3/4 R3/4
3.09-20.130-80-DE | 2024-01-15
l1 [mm] l2 [mm]
59 85
66 95
74 106
l3 [mm] l4 [mm]
26 52
29 58
34 66
H2 [mm]
21,5
21,5
23,5
l5 [mm] H1 [mm]
23,5 23,5
27 23,5
29 23,5
16 / 34
