Orbit Controls AG
[FUNC:]RES(?) <DNPD>
This command sets the output resistance value.
<DNPD>
Parameter represents the value of the output resistance expressed in Ω.
If query is sent, the instrument returns the value of output resistance using standard
exponential format. Example: 110.1 Ω is returned as 1.101000e+002.
Example:
Resistance 230.5Ω:
FUNC:RES 230.5
Note:
Command selects resistance output function.
[FUNC:]POW(?) <DNPD>
This command sets the output power value.
<DNPD>
Parameter represents the value of the output power expressed in W.
If query is sent, the instrument returns the value of output power using standard exponential
format. Example: 1101 W is returned as 1.101000e+003.
Example:
Power 230W:
FUNC:POW 230
Note:
Command selects power output function.
[FUNC:]CURR(?) <DNPD>
This command sets the output current value.
<DNPD>
Parameter represents the value of the output current expressed in A.
If query is sent, the instrument returns the value of output current using standard exponential
format. Example: 2 A is returned as 2.000000e+000.
Example:
Current 2.5A:
FUNC:CURR 2.5
Note:
Command selects current output function.
Betriebsanleitung
OCM-192 AC/DC Widerstandslast
22
