<05> - <0f> not used; available for future developments.
<10> command execution error.
<11> protocol data error.
<12> encoder data error.
<13> position data error.
<14> "Bluebus" error.
<15> memory error.
<16> - <ef> not used; available for future developments.
<f0> "BusT4" not operating.
<f1> not used; available for future developments.
• For EVT responses:
[x] reports the status of the automation. May take the following values:
<1> automation locked.
<2> automation unlocked.
<3> automation moving.
<f> no additional information.
Example – request to single motor automation, address 3 and endpoint 5, to move to the
fully open position:
"POS > 03 05 1000 FFFF F"
"POS # 03 05 1000 FFFF F"
"POS * 03 05 1000 FFFF F"
7.2 - "BusT4" commands: INF
INF commands return information about the devices on the "BusT4" line. The protocol is
as follows:
"INF [flag] [gg] [ee] [ww] [z] [yy]"
[flag] in combination with INF, defines the type of message sent:
GET command, used to request the principal information
<
about the devices on the "BusT4" line.
response of the interface (RSP) indicating that the GET
#
command has been received.
response of the interface (ERR) indicating a GET com-
!
mand syntax error.
response of the interface (EVT), sending the requested in-
*
formation.
[gg] address of the automation.
[ee] endpoint of the automation.
[ww] The meaning of the parameter depends on the [flag].
Indicates the type of information to be returned by a GET or RSP, EVT re-
sponse: For ERR responses, this parameter has no meaning:
<00> - <06> reserved for future implementations.
<07> mac address.
<08> manufacturer.
<09> product.
<0a> hardware version.
<0b> firmware version.
<0c> description.
<0d> - <fe> reserved for future implementations.
<ff> reserved value.
[z] Parameter composed of a variable length string.
Tells the operator which error has been detected, according to the follow-
[yy]
ing table:
<00> no error.
<01> command syntax error.
<02> command timeout.
<03> collision on "BusT4".
<04> device not found.
<05> - <0f> not used; available for future developments.
<10> command execution error.
<11> protocol data error.
<12> encoder data error.
<13> position data error.
<14> "Bluebus" error.
<15> memory error.
<16> - <ef> not used; available for future developments.
<f0> "BusT4" not operating.
<f1> - <ff> not used; available for future developments.
