EnGLIsh
nOTE: Edge grinding and cutting can be performed with
Type 27 wheels designed and specified for this purpose; 6 mm
thick wheels are designed for surface grinding while thinner
Type 27 wheels need to be examined for the manufacturer's
label to see if they can be used for surface grinding or only edge
grinding/cutting. A Type 1/41/Type A (cut‑off) wheel guard
must be used for any wheel where surface grinding is forbidden.
A Type 1/41/Type A (cut‑off) (previously called type 1/41) wheel
guard must be used for any dual purpose (combined grinding
and cutting‑off abrasive) wheels. Cutting can also be performed
by using a Type 1/41 wheel and a Type 1/41/Type A cut‑off
wheel guard, previously called Type 1/41 guard.
nOTE: Refer to Grinding and Cutting Accessory Chart to select
the proper guard/accessory combination.
Mounting and Removing a Fixed Screw Guard
(Fig. B)
1. Place the angle grinder on a table, spindle
2. Align the lugs with the slots
8
3. Press the guard 6 down and rotate it to the
required position.
4. Securely tighten the screw
5. To remove the guard, slacken the screw.

CAUTION: If the guard cannot be tightened by the
adjusting screw, do not use the tool. To reduce the risk of
personal injury, take the tool and guard to a service centre
to repair or replace the guard.
Mounting Closed (Type A) Guard
1. Open the guard latch. Align the lugs
the slots on the gear case.
9
2. Push the guard down until the guard lug engages and
rotates freely in the groove on the gear case hub.
3. Rotate guard into desired working position. The guard body
should be positioned between the spindle and the operator
to provide maximum operator protection.
4. Close the guard latch to secure the guard on the gear case
cover. You should be unable to rotate the guard by hand
when the latch is in closed position. If rotation is possible,
tighten the adjusting screw with the clamp lever in the
closed position. Do not operate grinder with a loose guard
or clamp lever in open position.
5. To remove the guard, open the guard latch, rotate the guard
so that the arrows are aligned and pull up on the guard.
nOTE: If, after a period of time the closed (Type 1) guard
becomes loose, tighten the adjusting screw with the clamp
lever in the closed position.

CAUTION: If the guard cannot be tightened by the
adjusting screw, do not use the tool. To reduce the risk of
personal injury, take the tool and guard to an authorized
repair agent to repair or replace the guard.
NOTICE: Do not tighten adjusting screw with clamp
lever in open position. Undetectable damage to guard or
mounting hub may result.
40
2 up.
.
9
.
11
on the guard with
8
Flanges and Wheels
Mounting Non‑Hubbed Wheels (Fig. D, E1, E2)

WARNING: Failure to properly seat the flange/ clamp nut/
wheel could result in serious injury (or damage to the tool
or wheel).

CAUTION: Included flanges must be used with depressed
centre Type 27 and Type 42 grinding wheels and
Type 41 cutting wheels. Refer to the Grinding and
cutting accessory chart for more information.

WARNING: A closed, two-sided cutting wheel guard is
re quired when using cutting wheels.

WARNING: Use of a damaged flange or guard or fail ure
to use proper flange and guard can re sult in injury due to
wheel breakage and wheel contact. Refer to the Grinding
and cutting accessory chart for more information.
1. Place the tool on a table, guard up.
2. Install the backing flange
centre (pilot) facing the wheel. Press the backing flange
into place.
3. Place the wheel on the backing flange
12
a wheel with a raised centre, make sure that the raised
centre 13 is facing the backing flange
4. Screw the locking flange
a. The ring on the locking flange
wheel when fitting a grinding wheel (Fig. E1);
b. The ring on the locking flange
the wheel when fitting a cutting wheel (Fig. E2).
5. Press the spindle lock button
until it locks in position.
6. Tighten the locking flange
7. Release the spindle lock.
8. To remove the wheel, reverse the above procedure.
Mounting Sanding Backing Pads (Fig. A, F)
nOTE: Use of a guard with sanding discs that use backing pads,
often called fiber resin discs, is not required. Since a guard is
not required for these accessories, the guard may or may not fit
correctly if used.

WARNING: Failure to properly seat the flange/ clamp nut/
wheel could result in serious injury (or damage to the tool
or wheel).

WARNING: Proper guard must be reinstalled for grinding
wheel, cutting wheel, sanding flap disc, wire brush or
wire wheel applications after sanding applications
are complete.
1. Remove the backing flange
2. Place or appropriately thread backing pad
the spindle.
3. Place the sanding disc
14
4. While depressing spindle lock button
nut 16 on spindle, piloting the raised hub on the clamp nut
into the centre of san ding disc and backing pad.
on spindle with the raised
4 2
. When fitting
4
4 .
5 onto the spindle 2 :
5 must face toward the
must face away from
5
1 and rotate the spindle
with the wrench supplied.
5
4 by pulling away from tool.
15 on
on the backing pad.
1 , thread clamp
2
