WIRING DIAGRAM
ASSIGNMENT OF THE SYSTEM CONNECTOR AT VN740-DBJ-CAN-4G
C
System cable set with CAN-Bus decoder (20-pin connector, black)
RCA white (AUX-L):
RCA red (AUX-R):
RCA yellow (CAMERA):
Cable orange (AMP CON):
The remaining cables and connections of the system cable set with CAN-Bus decoder
are not required.
AV CONNECTION ASSIGNMENT (GENERAL)
A
AV cable set 1 (14-pin connector, black)
RCA white (FL):
RCA red (FR):
RCA white (RL):
RCA red (RR):
RCA green (SUB WOOFER):
RCA yellow (VIDEO OUT 1):
RCA yellow (VIDEO OUT 2):
RCA yellow (AUX-V):
RCA yellow (REAR-CAMERA*):
* or REV-V
G
AV cable set 2 (8-pin connector, blue)
RCA red (AUX-RIN):
RCA white (AUX-LIN):
RCA yellow (FRONT-CAMERA*): Video input for the front or additional camera
Cable yellow (CCD+12V):
Cable black (GND):
Cable brown (BRAKE):
* or F-CAMERA
E
Camera cable set for HD rear view cam (10-pin connector, yellow)
RCA yellow (AHD-CAM):
Audio input for factory AUX connection / left
Audio input for factory AUX connection / right
Camera input for factory rear-view camera
Turn-on signal for external audio amplifier (+ 12V)
Audio output Front/Left
Audio output Front/Right
Audio output Rear/Left
Audio output Rear/Right
Audio output Subwoofer
Video output for external monitor 1
Video output for external monitor 2
Video input for an external signal source
Video input for rear view cam
Audio input AUX/Right
Audio input AUX/Left
Power cable for all cameras
Ground cable for all cameras
Connection for handbrake signal (ground)
Video input for high resolution rear view camera
(Only for compatible HD cameras)
