INSTALLATION INSTRUCTIONS VN1050-MA-DBJ-4G
Compatibility:
Fiat Ducato III (Type 250, since 2006), Ducato IV (Type 290, since 2015)
Citroën Jumper II (Type 250, since 2006), Jumper III (Type 290, since 2015)
Peugeot Boxer II (Type 250, since 2006), Boxer III (Type 290, since 2015)
Not compatible with Blind Spot Assist.
When replacing or removing original components such as the radio, depending on the equip-
ment of your vehicle, error messages or functional restrictions can occur if the appropriate
measures are not followed when installing the ESX Naviceiver. For example, after removing
the original radio, the on-board electronics cause an error message and the odometer read-
ing starts to flash. Under certain circumstances, this can only occur after you have driven a
few kilometers after the reinstallation.
Please note the following before starting the installation:
TYPE 250 since 2006 / Type 290 since 2015
Original equipment:
Connections on the vehicle side:
Required connection accessories:
Steering wheel remote control*:
TYPE 250/290 since 2015
Original equipment:
Connections on the vehicle side:
Required connection accessories:
Steering wheel remote control*:
TYPE 250/290 since 2015
Original equipment:
Connections on the vehicle side:
Required connection accessories:
Steering wheel remote control*:
Radio preparation
ISO connection without CAN bus
VNA-LFB-FD6 (included)
Must be trained in the Naviceiver.
See page 15 of the owner's manual.
Original radio / navigation system
CAN bus (52-pin)
USB port, AUX port
Rear view camera*
VNA-LFB-FD3.40
(included in VN740-DBJ-CAN-4G)
Immediately functional.
Blue & Me e.g. Radio Delphi F250FL
CAN bus on ISO connection
VNA-LFB-FD6 (included)
Must be trained in the Naviceiver.
See page 15 of the owner's manual.
* Depending on vehicle
