_Steam locomotive BR23.10___
4.1 Function mapping (Aspects)
The F0-F28 function buttons mapping to the outputs of the ECU is made in a double level scheme.
The group of outputs is controlled in the same time by a function is called Aspect. The ECU has a total
8 configurable Aspects. The setting for each Aspect is made in 3 CVs.
954.0 – 962.0 defines which function button (F0-F28) is controlling each Aspect
964.0 – 979.0 defines which outputs are active for each Aspect: even numbers for the forward
direction and odd numbers for reverse direction. These CVs are bit masks, each bit correponds to one
output. If the bit is set (bit value = 1) the corresponding output will be activated within the Aspect.
Note: The AUX7 output is not accessible to the user and is implementing a special function for the
shunting lights. It should be configured for the corresponding Aspect.
4.1.1 Output Bit mask
Each bit position corresponds to one output as it can be seen in the table below:
Bit position
( = 128)
Function output
AUX14
4.1.2 Default factory configured Aspect overview
Aspect1:
controls AUX9. Bit 2 is set in CV964.0 = 4 (forward direction) and CV965.0 = 4
(reverse direction). It is switched with function F5 defined in CV955.0 = 5.
Aspect2:
controls AUX10. Bit 3 is set in CV966.0 = 8 (forward direction) and CV967.0 = 8
(reverse direction). It is switched with function F6 defined in CV956.0 = 6.
Aspect3:
controls AUX14. Bit 7 is set in CV968.0 = 128 (forward direction) and CV969.0 = 128
(reverse direction). It is switched with function F13 defined in CV957.0 = 13.
Aspect4:
controls AUX11. Bit 4 is set in CV970.0 = 16 (forward direction) and CV971.0 = 16
(reverse direction). It is switched with function F7 defined in CV958.0 = 7.
Aspect5:
controls AUX8. Bit1 is set in CV972.0 = 2 (forward direction) and CV973.0 = 2 (reverse
direction). It is switched with function F4 defined in CV959.0 = 4.
Aspect6:
controls AUX7 (the shunting light). Bit0 is set in CV97.0 = 1 (forward direction)
and CV975.0 = 1 (reverse direction). It is switched with function F2 defined in CV960.0 = 2.
Aspect7:
controls the ouputs AUX12/AUX13 direction dependant (electrical coupling). Bit 6 is
set in CV976.0 = 64 (forward direction, AUX13) and Bit5 is set in CV977.0 = 32 (reverse direction,
AUX12). It is switched with function F12 defined in CV961.0 = 12.
Aspect8:
not used, can be freely programmed for other outputs (please see CV1018, CV1019,
CV962)
Bit7
Bit6
( = 64)
( = 32)
AUX13
AUX12
Bit5
Bit4
Bit3
( = 16)
( = 8)
AUX11
AUX10
7
Bit2
Bit1
Bit0
( = 4)
( = 2)
( = 1)
AUX9
AUX8
AUX7
