Knick Protos II 4400 Betriebsanleitung Seite 3

Inhaltsverzeichnis
Modul Protos COMFF 3400(X)-085
Rücksendung ............................................................................................................................... 2
Entsorgung ................................................................................................................................... 2
Warenzeichen .............................................................................................................................. 2
Bestimmungsgemäßer Gebrauch .................................................................. 5
Sicherheitshinweise ........................................................................................ 6
Betrieb in explosionsgefährdeten Bereichen: Modul COMFF 3400X-085 ............. 6
Firmwareversion ............................................................................................. 7
Foundation Fieldbus (FF)-Technik .................................................................. 8
Buskommunikation ................................................................................................................... 9
Klemmenschild ............................................................................................. 10
Modul einsetzen ............................................................................................ 11
Foundation Fieldbus Installation ................................................................. 12
Kommunikationsmodell ........................................................................................................14
Resource Block (RB) ................................................................................................................14
Analog Input Block (AI) ..........................................................................................................14
Analog Input Transducer Block (AI TB) ............................................................................14
Verbindungen (Channels) .....................................................................................................14
AI-TB Konfiguration am Gerät ..............................................................................................15
Busanschaltung ........................................................................................................................16
Kopiervorlage: Eigene Einstellungen .......................................................................17
Offline-Konfiguration..............................................................................................................18
Erst-Inbetriebnahme ...............................................................................................................20
Analog Input Blöcke ................................................................................................................21
Konfiguration der AI TB ..........................................................................................................22
Konfiguration mit Foundation Fieldbus ..........................................................................23
Inbetriebnahme am Foundation Fieldbus ......................................................................23
Inbetriebnahme und Konfiguration ..................................................................................24
Kalibrierprotokolle ...................................................................................................................28
Parameter der AI-Transducerblöcke ..................................................................................29
Funktionsblock AO ..................................................................................................................30
3
