Part Numbers Covered By This Manual; Standard Series; Small Diameter Series; Ht4 Series - norbar HANDTORQUE HT 1 Bedienungsanleitung

PART NUMBERS COVERED BY THIS MANUAL

This manual covers the setup and use of Norbar HandTorque

Standard Series

Maximum
Model
Torque
HT 1 & HT 2 1700 N·m
HT 5 & HT 6 3400 N·m
HT 7 6000 N·m
HT 9 9500 N·m
HT 11 20000 N·m
HT 12 34000 N·m
HT 13 47500 N·m

Small Diameter Series

Model Maximum Torque
HT 30
HT 60

HT4 Series

Model Maximum Torque
HT 4
HT 4

Compact Series

Model
HT-52 & HT-72
HT-72
HT-72
HT-92
HT-119
HT-52 (HandTorque
®
HT-72 (HandTorque
®
HT-92 (HandTorque
®
AWUR = Anti Wind Up Ratchet.
NOTE: For more information on HandTorque

Optional Extras

A range of Sockets, Nose Extensions and Annular Torque Transducers are available to suit the
HandTorque range.
®
