battery mountIng

Caution
• Do not mix old and new batteries/rechargeable batteries.
• Do not mix different types of batteries.
1
Remove screw of the battery-cover. Remove the cover.
3
Close the battery-case.

mountIng the lanDIng gear

Mounting
the landing
gear
GB // 24
• Do not charge non-rechargeable batteries.
2
Put fresh AA Mignon batteries with correct polarity into the
battery-case.
Please attach the landing gear to the underside of the quadcopter
using the screws supplied. (see illustration)
When tightening the screws please ensure that you do no
over-tighten them.
You should also re-tighten them periodically.
Mounting
the landing
gear
Recess
note
