2 - press the SET button briefly: this will enable the
programming of P1, start time ST1
3 -press the SET button briefly: select start time ST1.
The time field blinks, and the start time can be entered
by pressing the UP and DOWN buttons repeatedly
4 - press the SET button briefly to retain the selected
ST1 setting
5 press the SET button briefly: this will enable the
programming of P1, end time EN1
6 - press the SET button briefly to select the end time
EN1: the procedure is the same as for the start time ST1
(steps 3 and 4)
7 - press the SET button briefly: this will enable the
programming of profile 1, fan speed FN1
8 - press the SET button briefly to select the fan speed
FN1: the procedure is the same as for the start and end
times ST1 and EN1 (steps 3, 4) (selectable values are
1,2,3).
Thereafter, parameters ST2, EN2 and FN2, and
parameters ST, EN and FN for profile P2, can be
selected by means of the UP button, following the same
procedures as described above.
A time profile can be associated with a day of the week
by way of the following procedures:
Before proceeding with the steps indicated below, press
the ESC button to quit and return to the initial menu
(fig.27)
27
FIL T
1 2 3
esc
/ °C
By-Pass
1 from the initial "Prof" menu, press the UP button
briefly to enable programming of the day of the week
("day")
2 press the SET button briefly to enable programming of
the first day (mon: )
3 press the SET button briefly: the profile field (P1/P2)
blinks and the selection can be made pressing the UP
or DOWN button repeatedly
4 press the SET button briefly to retain the selected
profile setting
5 the procedure for associating a profile with following
days of the week remains the same: press the UP and
DOWN buttons to move on to the next day, then
repeat the procedure of steps 3 and 4.
P1
P2
4 5 6 7
set
Prg
Activation of operation using previously selected
profiles (fig.28)
Before proceeding with the steps indicated below, press
the ESC button to quit and return to the initial menu.
28
The time profiles selected previously can be selected as
follows:
- pressing and holding the ESC button, the "P1" or "P2"
icon will be displayed, depending on the selection
made previously when programming time profiles.
N.B. When operation according to profiles is activated,
all other functions managed by the panel (bypass,
speed) are inhibited.
Activation of time/outdoor temperature display
(fig.29)
Before proceeding with the steps indicated below, press
the ESC button to quit and return to the initial menu.
29
P1/P2
The current values of the "time" and "outdoor
temperature" parameters can be viewed in alternation
by pressing the ESC button briefly.
P1
P2
FIL T
1 2 3 4 5 6
esc set
Prg
/ °C
By-Pass
P1 P2
FIL T
1 2 3 4 5 6
esc set
Prg
/ °C
By-Pass
