ENGLISH
Selection of speeds (fig.23)
Before proceeding with the steps indicated below, press
the ESC button to quit and return to the initial menu.
23
FI LT
1 2 3
esc
/ °C
By-Pass
The fan speed is preset during configuration of the
appliance, and can be selected by pressing the UP
button briefly (3 settings are possible: 1=min Vel,
2=med Vel, 3=max Vel).
Setting the required room temperature (fig.24)
Before proceeding with the steps indicated below, press
the ESC button to quit and return to the initial menu.
24
FIL T
1 2 3
esc
/ °C
By-Pass
The preferred room temperature can be selected as
follows:
- press and hold the SET button;
- press the SET button briefly (current value blinks);
- select the required value using the UP and DOWN
buttons;
- press the SET button briefly to retain the setting;
- press the ESC button briefly to quit;
22
P1 P2
4 5 6 7
set
Prg
P1 P2
4 5 6 7
set
Prg
Activation of "bypass" function (fig.25)
The purpose of the bypass function is to ventilate the
dwelling without heat transfer. The opening of the by-
pass valves enables the direct introduction of external
air, without it passing through the exchanger. The flow of
air extracted from the house continues to pass through
the exchanger.
Before proceeding with the steps indicated below, press
P1/P2
the ESC button to quit and return to the initial menu.
25
The "by-pass" function can be forced by pressing and
holding the ESC button. The corresponding "money
box" icon will light up.
NOTE: this function becomes available once at least 10
minutes have elapsed following power-up of the
appliance. You will need to wait 10 minutes after each
activation/deactivation before using the by-pass
P1/P2
function.
Programming time profiles (fig.26)
Before proceeding with the steps indicated below, press
the ESC button to quit and return to the initial menu.
26
The panel allows the programming of time profiles: the
operating time profile is a set of parameters — a start
time, an end time and a fan speed — determining the
operation of the appliance for a given period. Two
profiles (P1 and P2) can be set by the user:
- P1, used to program two different periods of operation,
each with a start time, an end time and a fan speed;
- P2, used to program a single period of operation, with
a start time, an end time and a fan speed.
The profile can be assigned to a given day of the week.
The profiles can be programmed as follows:
1 - press the ESC and SET buttons together briefly: the
name of the initial menu is displayed: "Prof"
P1 P2
FIL T
1 2 3 4 5
6
esc set
Prg
/ °C
By-Pass
P1
P2
FIL T
1 2 3 4 5 6
esc set
Prg
/ °C
By-Pass
P1/P2
7
P1/P2
7
