Connecting Extension Hosepack Hp2X25Arctig - Fronius TTW 3600 ArcTig Bedienungsanleitung

Connecting ex- TTW 3600 ArcTig
tension hosepack
(A)
HP 2x25 ArcTig
(B)
1
1
NOTE!
If there is no interconnecting hose or if it is not connected correctly then the exten-
sion hosepack will not be cooled, which will lead to the extension hosepack becom-
ing damaged.
► Before switching on, check that the coolant hoses from gas nozzle cooling unit 2 are
► Check the connections for leaks!
Torch hosepack
Extension hosepack
connected by an interconnecting hose.
(B)
(A)
