GB
Thank you for choosing the Super Crono
Power Fluid
IMPORTANT
Do not stop the rotation of the bicycle
wheel by using caliper or disk brake. This
seriously damages the roller and the tire.
INTRODUCTION
Check the presence of all the following compo-
nents.
1 Power Fluid unit (Ref. A)
1 stand (Ref. B)
1 left bushing pin (Ref. C)
1 ring (Ref. D)
1 right bushing pin (Ref. E)
1 fixing lever (Ref. F)
1 unit support upper base (Ref. G)
1 unit support lower base (Ref. H)
1 screw M6 x 45 mm (Ref. I)
1 washer Ø6 mm (Ref. L)
1 nut M6 (Ref. M)
1 bag of unit accessories:
1 hex wrench
2 screws M6 x 55 mm (Ref. N)
2 washers Ø6 mm (Ref. O)
1 Quick release (Ref. P)
14
