And finally...

1
2
3
4
X13
(16)
(15)
Replace the cover
Secure the cover with seven TX25 screws
Tightening torque = 3 Nm
Secure the device to the robot
Establish connections to the other system components
Connect the cable (17) to the sensor
5
(8) and X13 on the PC board
Fix cable (17) in place with two cable
6
ties (15) and (16)
Trim the cable ties as required
7
(8)
(17)
