Installation over-
The OPT/i gas controller can be installed in the following devices:
view
-
-
NOTE!
The procedure below describes the installation of an OPT/i gas controller on a WF
25i R.
The installation process is the same on all other compatible devices, however the locati-
ons of the relevant components and/or connection sockets may differ from model to
model. The main process steps are always the same:
1
2
3
4
5
For more details on installation, see the following section.
Overview of correctly installed OPT/i gas controller:
(1)
(1)
Disconnect the device from all other system components
Place the device on a temporary backing
Remove 4 TX 20 screws (1)
Open the wirefeeder cover (2)
Remove the wirefeeder housing cover (3) from the unit as shown
all variants of the WF 15/25/30i R robot wirefeeders
all variants of the SB 500i R SplitBox
Remove the gas solenoid valve installed in the device
Install the new gas solenoid valve
Install the gas sensor
Connect the OUT connection socket of the gas sensor to the motor plate using a gas
hose
Connect the IN connection socket of the gas sensor to the gas solenoid valve using
a gas hose
(1)
(2)
(3)
(1)
