Control Board
The Control Board offers several features: you can e. g. simply set the starting address.
Browse through the menu by pressing Menu. You can change the selection by pressing Up or Down. You
can leave every mode by pressing the Menu-button. The functions provided are described in the following
sections.
Main menu
512
SNd
P - 1 – P - 5
P__
PAnn
tiln
rESt
DMX-controlled operation
You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.
Addressing
The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the DJ-LED Scan 15 will respond to the controller.
If you set, for example, the address to channel 9, the device will use the channel 9 to 16 for control.
Please, be sure that you don't have any overlapping channels in order to control each DJ-LED Scan 15
correctly and independently from any other fixture on the DMX data link.
If two, three or more DJ-LED Scan 15 are addressed similarly, they will work similarly.
For address setting, press the Menu button until the display shows „512" and set the desired address via the
Up/Down-buttons.
Controlling:
After having addressed all DJ-LED Scan 15, you may now start operating these via your lighting controller.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.
Display Function
With this function, you can adjust the desired DMX-address via
d001-d512
the Control Board.
With this function, you can adjust the sound-controlled mode.
The device features a built-in microphone and a rotary-control on
the rear panel to adjust the sound sensitivity.
With this function, you can adjust the automatic program
mode. You can choose between five different internal programs.
With this function you can reverse the Pan-movement.
PAnn PAnn positiv
PAnY PAnY reverse
With this function you can reverse the Tilt-movement.
tiln tiln positiv
tilY tilY reverse
With this function you can Reset the device via the Control
On/Off
Board.
