Step 1
Open the pre-assembled Main Frame, which is composed of parts (01) and (03). Insert Lock Pin
(41) through the holes of the pre-assembled Main Frame.
Step 2
Insert each Adjustable Pivot Bar (02L) & (02R) to Rear Support Tube (03), then secure it with 2
Washers (18), 2 End Caps (19), 2 M8 Flat Washers (52) and 2 M8*15mm Allen Bolts (46).
Install the pre-assembled Barrier tube (10) to Front support frame (01), then secure it with 1 M8
Arc washer (53) and 1 M8*55mm Allen bolt (44).
03
41
03
02L
02R
17
18
19
52
46
01
46
19
18
17
52
10
53
44
01
