How to remove the front grille and the speaker unit

1) Use the grille removal tool for removing the front
grille if you would like to adjust the tweeter
response switch e. g. (see picture).
2) After removing the front grille, unscrew the six
outer screws by means of the
driver.
Keep the screws in a safe place. You will use them
for later installations..
Do not touch the diaphragms of the drivers
when installing or removing the loudspeaker. If
the diaphragms are pressed too hard, they will
be damaged.
3) Use the grille removal tool for removing the
loudspeaker unit.
Carefully insert the grille removal tool into the little
hole on the front of the speaker unit and make sure
that the speaker unit does not fall down!
Phillips hand screw
