Fuels have only a limited shelf-life, they are subject to
ageing. Outdated fuels and fuel mixtures may result
in starting problems. Therefore, mix only that quan-
tity of fuel which you can use within a month. Only
store fuels in containers approved and identified for
this. Keep fuel containers in a dry and safe area.
Make sure that fuel containers are kept out of the
reach for children.
Caution! Prior to starting the machine learn how to
put it out of action in emergency cases.
Fuelling the hedge trimmer
• Stop the engine and allow it to cool down.
• Wear protective gloves.
• Avoid eye and skin contact.
• Strictly follow the instructions under "Safe handling
with fuels".
1. Only fuel the hedge trimmer in the open or in suf-
ficiently ventilated rooms.
2. Clean the area around the filler neck. Contamina-
tion in the tank may result in malfunction.
3. Shake the container once more before pouring
the fuel mixture into the tank.
4. Carefully open the tank cap (10) to allow possible
overpressure to relax.
5. Carefully fill the fuel mixture up to the lower edge
of the filler neck.
6. Close the tank cap. Check that the tank cap is
tight.
7. Clean the tank cap and the area around it.
8. Check the tank and the fuel lines for leaks.
9. Operate the fuel pump (11) if required.
10. Before starting the engine go away at least three
metres from the fuelling place.

8. Attachment and operation

You may not start to operate the machine until you
have read these operating instructions, observed all
the instructions given and completely and properly
assembled the machine!
- Make sure that the ON/OFF switch (6), the throttle
lock-out switch (7) and the throttle trigger (14) func-
tion perfectly.
- This hedge trimmer is only allowed to be started
after it is completely assembled.
- Support the hedge trimmer when starting and hold
it firmly. Make sure that the cutting device can
move freely.
To start the hedge trimmer:
1. Keep a safe distance to flammable materials.
2. Have a safe standing position.
3. Place the hedge trimmer on the ground in front of
you, with the cutting device showing away from
your body.
4. Put the right foot tip in the rear handle.
5. Hold the front handle with your left hand.
 www.scheppach.com /  service@scheppach.com /  +800 4002 4002
Starting with cold engine
1. Slide the ON/OFF switch (6) to the position „I„.
2. Carefully press on the fuel pump (11) several
times until fuel comes into the pump.
3. Slide the choke (4) to „cold start".
4. Slowly pull the cranking rope with its handle (5)
until you feel a resistance.
5. Pull the cranking rope quickly and then guide
it back slowly. Do not fully pull out the cranking
rope and do not allow that the cranking handle
strikes against the engine.
6. When the engine starts slide the choke (4) to
„warm start and work".
7. Allow the device to warm up for approx. 1 minute
before starting the work.
Stopping the engine
1. Release the throttle trigger (14).
2. Slide the ON/OFF switch (6) to the „0„ position.
Starting with warm engine
1. Slide the ON/OFF switch (6) to the position „I„.
2. Slide the choke lever (4) to „warm start and work".
3. Hold the cranking handle (5) and pull the crank-
ing rope until the engine starts.
Throttle lock-out switch
1. Hold the hedge trimmer on its rear handle (15)
and press the throttle lock-out switch (7).
2. Hold the front handle (3) with your other hand.
3. Press the throttle trigger (14).
4. The cutting device will start moving.
• If you release the throttle trigger, the cutting device
will stop and the engine will idle.
If the cutting device runs in spite of non-pressed
throttle trigger, you have to reduce the idle speed.
(See "Maintenance".)
Adjustments on the hedge trimmer
Adjusting the rear handle (15).
To make working with the hedge trimmer easier it is
possible to choose one of the 3 working positions of
the rear handle.
• When adjusting the throttle trigger (14) can not be
pressed.
1. Use your left hand to hold the hedge trimmer on
its front handle (3).
2. Pull the slider (13) and turn the handle to your de-
sired position.
3. Release the slider (13). Make sure that the un-
locking device engages again and that the handle
is secured.
GB | 23
