12. Install the Carbon Fiber Bracket onto the right side of the sub frame, using bolts, washers and Aluminium distance
bushes from Akrapovič installation kit (F 33).
IMPORTANT: use bolt sealant on the bolt threads!
13. Correctly position the carbon-fiber clamp (check the position of the yellow sticker) and carefully slide it onto the
muffler (F 34).
IMPORTANT: open the carbon-fiber clamp slightly wider than the diameter of the outer sleeve of the muffler
– do not scrape it along the muffler outer sleeve!
22Nm
16ftlb
DISTANCE
BUSH
WASHER
F 33
F 34
22 / 28
