3
Installation
3.3.2 Air Outlet In A Recycling Hood
Version
• In case the components requested for the
recycling functioning have been removed earlier
these have to be positioned again.
• Put the plastic tube onto the flange 7.
• Place the air outlet grid 8 on the air outlet.
Make sure that the position of the grid is cor-
rect.
• Make sure that charcoal filters have been pla-
ced inside the hood.
Hood / User Manual
3.4 Electrical Connection
• Connect the hood to the mains through a two-
pole switch having a contact gap of at least 3
mm.
• Remove the grease filters (see paragraph
Maintenance) being sure that the connector of
the feeding cable is correctly inserted in the
socket placed on the side of the fan.
9 / 51 EN
